  • Omini Light - OML-WIFI-GLN
    +

    Omini Light alarm clock with night light, wireless phone charger and 3K Wi-Fi security camera

    This guide walks you through setting up your Omini Light one step at a time. It takes about 10 minutes. All you need is your phone and your home Wi-Fi password.

    Omini Light is a bedside alarm clock with a warm night light and a 15 W wireless phone charger, with a 3K SuperHD Wi-Fi security camera built in. You watch it on your phone with the free Tuya Smart app. There is no monthly fee.

    Part 1: Get to know Omini Light

    Front

    Front of Omini Light labeled: setting buttons, display, night light touch button, night light, wireless charging pad, charging indicator light

    • Setting buttons on top, left to right as you face the display: Alarm, Time, SNOOZE, + and −.
    • Display: time, date, day and room temperature.
    • Camera: looks out from the front of the clock, through the display, the same way the display faces.
    • Night light touch button: the silver button on the side.
    • Wireless charging pad with a fabric top, and the charging indicator light on the front edge of the base.

    Back

    Back of Omini Light labeled: setting buttons, reset hole, microSD card slot, USB-C power port

    • microSD card slot: the thin slot in the middle of the back of the clock. You only need a card if you want to save videos.
    • Reset hole: the small round hole just to the right of the card slot (as you look at the back).
    • USB-C power port: at the bottom of the back, under the clock.
    • If your Omini Light has a silver sticker over the card slot, peel it off before you insert a card.

    Underside

    Underside of the base labeled: non-slip feet, backup battery door (CR2032, installed), alarm speaker, USB-C port

    Under the base are the backup battery for the clock (a CR2032 coin cell, already installed), the alarm speaker and non-slip feet.

    In the box: Omini Light, USB-C power cable, USB wall adapter, CR2032 backup battery (installed), user manual. A microSD card is sold separately.

    The clock, night light and wireless charger work as soon as Omini Light is plugged in, whether or not you set up the camera.

    Part 2: Before you start

    Have these ready:

    • ☑ Your phone (iPhone or Android).
    • ☑ Your home Wi-Fi name and password. Omini Light is dual-band (2.4 GHz and 5 GHz); setup uses your home's 2.4 GHz network.
    • ☑ A microSD memory card (optional) if you want to save videos. Use a Class 10 card, up to 256 GB.
    • ☑ A pin or straightened paperclip for the reset hole.

    Part 3: Set up the camera (8 steps)

    Step 1: Peel off the display film

    New units have a clear protective film on the front of the display. Peel it off. The camera looks out through the display, so the film blurs the picture and can stop the QR code from being read.

    Step 2: Put in the memory card (optional)

    Make sure Omini Light is not plugged in. Turn it around so you're looking at the back of the clock. Slide the microSD card into the thin slot and push gently until it clicks. If it stops halfway, take it out, turn it over and try again; don't force it.

    Close-up of the back of the clock: microSD card slot with the reset hole just to its right

    To take the card out later, unplug Omini Light, then push the card in once and it pops out.

    Step 3: Plug it in

    Connect the included USB-C cable to the port at the bottom of the back, and plug the other end into the included wall adapter. Plug the adapter into a wall outlet.

    The display lights up, the clock beeps, and the charging light on the front edge of the base flashes red and green, then turns green. Give the camera about 30 seconds to start.

    The camera, night light and charger work only while Omini Light is plugged in. Leave it plugged in so the camera can watch around the clock.

    Step 4: Get the free Tuya Smart app

    On your phone, open the App Store (iPhone) or Google Play (Android), search for Tuya Smart and install it. It may be listed as "Tuya – Smart Life, Smart Living".

    Open the app, tap Sign Up, enter your email address, and follow the steps to create a password. When the app asks, tap Allow for notifications (so you get motion alerts) and for location (so the app can see your Wi-Fi network during setup).

    Step 5: Reset the camera

    When the camera is ready to be added, you hear a prompt tone or a voice prompt such as "Ready to pair". If you don't hear it, or the camera was set up before, reset it:

    1. Keep Omini Light plugged in.
    2. Push a pin or paperclip into the reset hole on the back of the clock, next to the card slot.
    3. Hold it for about 5 seconds until you hear the reset prompt, then let go.
    4. Wait for "Ready to pair" before you go on.

    Resetting the camera does not change the clock, the alarm or the night light.

    Step 6: Add the camera in the app

    Connect your phone to your home's 2.4 GHz Wi-Fi and keep it close to Omini Light and your router. On iPhone, turn off Mobile Data and Wi-Fi Assist for a few minutes while you set up.

    On the app's home screen, tap Add Device (or + at the top right). Choose Camera & Lock on the left, then tap Smart Camera (Wi-Fi). Read the four setup tips and tap Next after each one.

    Tuya Smart app: tap Add Device, then Camera & Lock, then Smart Camera (Wi-Fi)

    The tips show a generic camera. On Omini Light, you show the QR code to the front of the display, and the reset hole is on the back of the clock.

    Step 7: Enter your Wi-Fi and show the QR code

    1. Choose your 2.4 GHz Wi-Fi network, type the password carefully (capital letters matter) and tap Next.
    2. The app shows a QR code. Turn your screen brightness up and hold the phone with the screen facing the front of Omini Light's display, 6 to 8 inches away.
    3. When you hear the prompt tone, tap "I Heard a Prompt".

    Tuya Smart app: choose your 2.4 GHz Wi-Fi and enter the password, then the app shows a QR code

    Hold the phone's QR code 6 to 8 inches from the front of the Omini Light display

    No beep? Slowly move the phone a little closer and farther away, and a little left and right across the display, until you hear it.

    If you typed the wrong Wi-Fi password, reset the camera (Step 5) and start this step again.

    Step 8: Wait while it connects

    Connecting can take up to two minutes. Keep your phone near Omini Light. When you see Added successfully, tap the pencil icon to rename the camera if you like (for example, "Bedroom" or "Living Room"), then tap Done.

    Tuya Smart app connecting to the camera, then Added successfully

    The camera now shows on your home screen. Tap it to watch live, from anywhere.

    If it says "Failed to add the device": check that Omini Light is plugged in, your phone is on the 2.4 GHz network, the password is correct, the display film is off, and you heard a beep after showing the QR code. Then reset the camera (Step 5) and tap Retry. The first try sometimes fails because of the Wi-Fi signal; that's normal.

    Part 4: Everyday use

    Watch live, take a photo, record a clip

    Tap the camera on the app's home screen to open the live view.

    • Tap HD / SD to switch the picture quality. Use SD if your connection is slow.
    • Tap Photo or Video to save a picture or a clip to your phone. Find them under Gallery.
    • Tap the speaker icon to turn the sound on or off. Sound is available only on the Video + Audio version, which is for in-home use only.

    Get an alert when there is motion

    1. In the live view, turn on Motion Detection.
    2. To change the sensitivity, tap ··· at the top right, then Detection Alarm Settings, and pick High, Medium or Low. Choose Low if you get too many alerts, High if you miss things.
    3. Tap Messages at the bottom of the camera screen to see recent alerts.

    Also check that notifications for Tuya Smart are allowed in your phone's settings.

    Save videos to the memory card

    With a card in, tap ··· and scroll down:

    • Storage Settings: tap Format the first time you use a card. (This erases everything on the card.)
    • Recording settings: turn on Local Recording, then choose non-stop recording or event recording only (when there is motion), and set a schedule if you like.

    Tuya Smart app storage and recording settings for the microSD card

    A 256 GB card holds about 128 hours of 3K video. To watch what was recorded, tap Playback, pick a date and drag the timeline. You can download clips to your phone.

    Other settings

    • Flip Screen (··· → Basic Function Settings): turns the picture upside down if it looks wrong.
    • Share Device (in the camera's ··· settings): gives someone in your household their own access with their own Tuya Smart account.

    Part 5: Clock, alarm and display

    The clock works on its own, separate from the camera and the app. Use the five buttons on top.

    AlarmSet the alarm time; turn the alarm on or off
    TimeSet the time and date
    SNOOZE10 more minutes when the alarm rings (up to 3 times); at other times, changes the screen brightness
    +Increase a setting; switch between 12-hour and 24-hour time
    −Decrease a setting; switch the temperature between °F and °C

    Set the time and date

    1. Press and hold Time until the hour flashes.
    2. Press + or − to change it, then press Time to move on to the minutes, year, month and date.
    3. After the last item, or a few seconds without pressing a button, the clock saves your settings.

    Set the alarm

    1. Press and hold Alarm until the alarm hour flashes.
    2. Press + or − to set the hour, press Alarm, then set the minutes the same way. Press Alarm to save.
    3. Press Alarm briefly to turn the alarm on or off. The alarm icon shows on the display when it is on.

    When the alarm rings, press SNOOZE for 10 more minutes, or press Alarm to stop it.

    Screen brightness

    When the alarm isn't ringing, press SNOOZE to step the screen through bright, medium, low and off.

    Backup battery

    A CR2032 coin cell comes installed under the base. It keeps the time and settings if the power goes out. If the clock starts losing its settings after a power cut, slide open the battery door on the underside and replace the coin cell (+ side up).

    Part 6: Night light and wireless charging

    Night light

    Touch the silver button on the side to go from off to low, medium and high, and back to off. The night light is separate from the screen brightness and from the camera.

    Wireless charging

    Lay a phone (or earbud case) that supports Qi wireless charging in the middle of the fabric pad, screen up. Phones that support fast wireless charging get up to 15 W; others charge at their own wireless speed.

    Red, breathingCharging
    OffFully charged
    Red and green flashingCheck for a metal object on the pad (keys, coins, a metal plate or card in the case) and remove it
    GreenReady, nothing charging
    • Use the included wall adapter. A weaker USB adapter can slow charging or stop it.
    • Take off thick, metal or magnetic cases and card wallets before charging.
    • Never leave metal objects, credit cards, key cards or anything with a magnetic strip on the pad.

    Part 7: Where to put it

    • Turn the display toward the area you want to watch. The camera sees what the display faces, with an 80° view.
    • Keep the front of the display clear of photos, bottles and other objects.
    • A dresser, shelf or desk gives a more natural view of the room than a low nightstand.
    • Open the live view and turn Omini Light until the area you care about is in frame.
    • Omini Light has no infrared night vision. Its night light is made for the nightstand, not for lighting the room. For video at night, leave a lamp or night-light on in the area you want to see.
    • Keep it indoors, in a dry place, within good range of your Wi-Fi router.

    Part 8: If something isn't working

    I don't hear "Ready to pair", or the app can't find the camera.
    Reset the camera: hold the reset hole on the back of the clock for about 5 seconds and wait for the ready prompt.

    The QR code scan doesn't work.
    Peel off the display film, turn your screen brightness up, and hold the phone 6 to 8 inches from the front of the display. Move it slowly closer, farther, and a little left and right.

    The app can't find my Wi-Fi network.
    Turn on location permission for Tuya Smart in your phone's settings. If your router only shows a 5 GHz network, turn on its 2.4 GHz band. Networks with a sign-in page, like hotel or some guest networks, won't work.

    The camera says Offline.
    Check that Omini Light is plugged in and your internet is working, and move it closer to the router. If you changed your Wi-Fi name or password, reset the camera and add it again.

    The picture is dark at night.
    Omini Light has no infrared night vision. Leave a light on in the area you want to see.

    The video freezes or is choppy.
    Switch the live view to SD, or move Omini Light closer to your router.

    The memory card isn't recognized, or nothing is recorded.
    Use a Class 10 card, 256 GB or smaller. Unplug Omini Light, push the card in until it clicks, plug it back in, then format the card in Storage Settings and make sure Local Recording is on.

    I'm not getting motion alerts.
    Make sure Motion Detection is on, the sensitivity isn't too low, and notifications for Tuya Smart are allowed in your phone's settings.

    My phone isn't charging.
    Make sure your phone supports Qi wireless charging, take off thick or metal cases, and center the phone on the pad. If the light flashes red and green, remove any metal object from the pad.

    The clock lost its time after a power cut.
    Replace the CR2032 coin cell under the base, then set the time again.

    Screens may look a little different depending on your phone and your version of the Tuya Smart app.

    Specifications

    Video3K SuperHD, 2880 x 1620
    Viewing angle80°
    Low lightLow-light video sensor; no infrared night vision
    AudioVideo-only version, or video + audio version (in-home use only)
    Wi-FiDual-band, 2.4 GHz and 5 GHz (set up on 2.4 GHz)
    AppTuya Smart for iPhone and Android (free)
    Memory cardmicroSD up to 256 GB, Class 10 (not included); about 128 hours on 256 GB
    Clock12 or 24-hour; alarm with 10-minute snooze (up to 3 times); date, day and room temperature in °F or °C
    Display3 brightness levels or off
    Night lightWarm white, 2900–3100 K, 3 levels, touch button
    Wireless chargingQi, up to 15 W (5 / 10 / 15 W)
    PowerUSB-C, 9 V / 2.1 A; USB-C cable and wall adapter included
    Clock backupCR2032 coin cell (installed)
    SizeAbout 5.9 x 4.1 x 5.7 in (W x D x H)
    WeightAbout 15.4 oz
    UseIndoor
    Monthly feeNone

    Safety

    • Use indoors, in a dry place. Use the included USB-C cable and wall adapter.
    • Coin cell batteries are dangerous if swallowed. Keep new and used CR2032 batteries away from children and pets, and keep the battery door closed. If you think a battery may have been swallowed, get medical help right away.
    • Unplug Omini Light before inserting or removing the memory card, or before cleaning. Clean the display with a soft, dry cloth.

    Use it responsibly

    Omini Light is a security camera for your own home, office or property. Let the people who live or work there know a camera is in use, and don't place it in bathrooms, bedrooms used by others, rentals where guests stay, or anywhere people expect privacy. The audio version is for in-home use only. Recording laws vary by state, and recording audio usually requires the consent of the people being recorded. It is your responsibility to follow all local, state and federal laws on video and audio recording.

    Need help?

    Zetronix tech support is free by phone, live chat and email from our US-based team. Visit the Zetronix Help Center to get in touch.

    View Omini Light on zetronix.com


  • Koios Pro 4K - PRO-KOIOS-4K
    +

    Koios Pro 4K camera and USB wall charger

    This guide walks you through setting up your Koios Pro 4K one step at a time. It takes about 10 minutes. All you need is your phone and your home Wi-Fi password.

    Koios Pro 4K is a Wi-Fi security camera built into a USB wall charger. You watch it live in 4K on your phone with the free LookCam app, and it records in 1080p Full HD. There is no monthly fee.

    Part 1: Get to know your camera

    Front of Koios Pro 4K labeled: microSD card slot, reset hole, camera lens, night-vision lights, USB-C port, USB-A port

    • microSD card slot: the memory card goes here. You only need a card if you want to save videos.
    • Reset hole: the small round hole at the top right. You only use it if something goes wrong.
    • Camera lens in the middle (4K live view, 1080p recording), with night-vision lights on both sides so you can see in the dark.
    • USB-C and USB-A ports: plug in your phone or other devices to charge them, like a normal charger.

    In the box: Koios Pro 4K camera charger, USB card reader, user manual. A microSD card is sold separately.

    Part 2: Before you start

    Have these ready:

    • ☑ Your phone (iPhone or Android).
    • ☑ Your home Wi-Fi name and password. Write them down. Koios Pro 4K works with 2.4 GHz and 5 GHz Wi-Fi.
    • ☑ A wall outlet indoors, with a clear view of the room.
    • ☑ A microSD memory card (optional) if you want to save videos. Use a Class 10 card, up to 256 GB.

    Part 3: Set up your camera (8 steps)

    Step 1: Put in the memory card (optional)

    Make sure the camera is not plugged in. Slide the microSD card into the slot on the front, above the lens, and push gently until it clicks.

    To take the card out later, unplug the camera, then push the card in once and it pops out.

    Step 2: Plug in the camera

    Plug Koios Pro 4K into the wall outlet. It turns on by itself. Wait 1 minute before you go on.

    Step 3: Get the free LookCam app

    On your phone, open the App Store (iPhone) or Google Play (Android), search for LookCam and install it.

    When the app asks, tap Allow for notifications (so you get motion alerts) and, on iPhone, for finding devices on your network.

    Step 4: Connect your phone to the camera

    The camera makes its own Wi-Fi network. Let's connect your phone to it.

    1. On your phone, open Settings, then Wi-Fi.
    2. Look for a network with a long name made of letters and numbers. That is your camera.
    3. Tap it to connect. It is fine if it says "No internet" or "Connected without internet."

    Phone Wi-Fi settings: tap the camera's network, a name made of letters and numbers

    Tip: If your phone keeps jumping back to your home Wi-Fi, turn off Mobile Data (and Wi-Fi Assist on iPhone) for a few minutes while you set up.

    Step 5: Open LookCam and add the camera

    Open the LookCam app. It finds the camera on its own and asks to add it. Tap OK.

    LookCam asks to add the new camera. Tap OK.

    If your phone shows "Internet may not be available", tap Keep Wi-Fi connection.

    Message 'Internet may not be available': tap Keep Wi-Fi connection

    Step 6: See your camera

    Your camera now shows in the app with the words Device Online. (Your camera's name will be different from the picture.)

    LookCam My Device screen showing the camera with Device Online

    Tap the camera's picture to watch it live.

    • If the app asks you to make a new password, you can tap Cancel for now.
    • If the app asks for the camera's password, type 123456.

    Right now you can watch only when your phone is near the camera. Steps 7 and 8 let you watch from anywhere.

    Step 7: Connect the camera to your home Wi-Fi

    1. In LookCam, tap the gear icon ⚙ next to your camera.
    2. Tap WiFi Setting.

    Tap the gear icon next to the camera, then tap WiFi Setting

    1. Tap your home Wi-Fi in the list.
    2. Type your Wi-Fi password carefully (capital letters matter) and tap OK.

    Pick your home Wi-Fi from the list, type its password and tap OK

    1. You will see "Saved, device will reboot." Tap OK and wait 1 minute while the camera restarts.

    Message 'Saved, device will reboot': tap OK and wait about a minute

    Step 8: Put your phone back on your home Wi-Fi

    1. Open your phone's Settings, then Wi-Fi, and tap your home Wi-Fi.
    2. Turn Mobile Data back on if you turned it off.
    3. Open LookCam. When your camera says Device Online, you are done!

    You can now watch your camera from anywhere, on Wi-Fi or mobile data.

    Part 4: Everyday use

    Watch live, take a photo, record a clip

    Open LookCam and tap your camera's picture. Live view streams in 4K. Under the video:

    • Tap the camera button to take a photo.
    • Tap the video button to record a clip. Tap it again to stop.

    Tap the camera picture to open live view; the camera button takes a photo and the video button records

    Night vision turns on by itself when the room gets dark. The picture turns black and white, and you can see up to about 40 ft.

    Save videos to the memory card

    1. Tap the gear icon ⚙ next to your camera, then SD Card Setting.
    2. The first time, tap Format sdcard to get the card ready. (This erases everything on the card.)

    Device Setting: tap SD Card Setting, then Format sdcard

    1. To record all the time, turn on Auto Record and Loop Record. When the card is full, the oldest videos are replaced by new ones, so it never stops recording.
    2. Video Duration sets how long each video file is (for example, 5 minutes).

    SD Card Setting with Auto Record and Loop Record turned on

    Record only when something moves

    In SD Card Setting, turn Auto Record off and turn Alarm Record on. The camera then saves video only when it sees movement, which saves space on the card.

    SD Card Setting with Alarm Record turned on to record only when there is motion

    Get an alert on your phone when there is motion

    1. Tap the gear icon ⚙, then Alarm Config.

    Device Setting: tap Alarm Config

    1. Turn on Push Notifications.
    2. Tap Motion Detection Sensitivity and pick Low, Medium or High. Choose Low if you get too many alerts, High if you miss things.
    3. Tap OK to save.

    Alarm Config: turn on Push Notifications and choose the Motion Detection Sensitivity

    The camera notices movement up to about 20 ft away. Also check that notifications for LookCam are turned on in your phone's settings.

    Watch your saved videos and photos

    At the bottom of the LookCam main screen:

    • Tap Cloud/SD to watch videos saved on the memory card.
    • Tap Photo to see the photos and clips you saved from live view.

    LookCam bottom menu: Photo for snapshots, Cloud/SD for recorded videos

    On a computer: unplug the camera, take out the memory card, put it in the included USB card reader and plug that into your Windows PC or Mac. If a video won't play, use the free VLC media player.

    Charge your phone

    The USB-C and USB-A ports on the front work like a normal charger, even while the camera is recording. Let the cables hang down so they don't block the lens.

    Part 5: Where to put it

    • Pick an indoor outlet with a clear view of the room.
    • Don't point it through a window or glass. At night the glass reflects the light back and the picture turns white.
    • Keep it close enough to your Wi-Fi router for a good signal.
    • Keep it away from water, sinks and damp areas.

    Part 6: Reset the camera

    Reset if you get a new Wi-Fi router, change your Wi-Fi password, forget the camera's password, or the camera won't connect.

    1. Keep the camera plugged in.
    2. Find the reset hole (the small round hole at the top right of the front; see Part 1).
    3. Push a paperclip or pin into the hole and hold it for 15 seconds.
    4. Wait 2 minutes, then start again at Step 4.

    A reset clears the Wi-Fi and password settings.

    Part 7: If something isn't working

    I can't find the camera's network in my Wi-Fi list.
    Wait 2 minutes after plugging it in. If it still isn't there, unplug the camera for 10 seconds and plug it back in. If the camera was already connected to your home Wi-Fi, it won't show its own network; reset it (Part 6) to start over.

    LookCam doesn't find the camera.
    Check that your phone is connected to the camera's network (Step 4). Turn off Mobile Data, then close LookCam and open it again.

    The camera says Offline.
    Check that the outlet has power (some outlets are controlled by a light switch) and that your home internet is working. Move the camera closer to your router. If you changed your Wi-Fi name or password, reset the camera and do Steps 4 to 8 again.

    The camera won't join my home Wi-Fi.
    Re-type the Wi-Fi password carefully; capital letters matter. Wi-Fi networks with a sign-in page, like hotel or some guest networks, won't work.

    I'm not getting motion alerts.
    Make sure Push Notifications is on in Alarm Config, and that notifications for LookCam are allowed in your phone's settings. Check that Do Not Disturb is off.

    Videos aren't being saved.
    Check that the card is pushed all the way in (always with the camera unplugged). Format the card in SD Card Setting, and make sure Auto Record or Alarm Record is turned on. Use a Class 10 card, 256 GB or smaller.

    The video freezes or is choppy.
    4K live view needs a good internet connection. In live view, tap the quality label at the top right (for example 4K) and choose a lower quality.

    I forgot the camera's password.
    Reset the camera (Part 6). The password goes back to 123456. When you make a new password, use only letters and numbers.

    Screens may look a little different depending on your phone and your version of the LookCam app.

    Specifications

    Live view4K in the LookCam app
    Recording1080p Full HD, 1920 x 1080, color by day
    Frame rate25 fps
    Lens140° wide angle
    Night vision4 infrared LEDs, up to 40 ft, black and white
    Motion detectionPhone alerts, up to about 20 ft
    AudioVideo-only version, or video + audio version (in-home use only)
    Wi-Fi2.4 GHz and 5 GHz
    AppLookCam for iPhone and Android (free)
    Memory cardmicroSD up to 256 GB, Class 10 (not included)
    USB charging1 x USB-C, 1 x USB-A
    PowerStandard US wall outlet; no battery
    SizeAbout 2.3 x 1.5 x 1.8 in, plus the plug
    Operating temperature14°F to 140°F
    UseIndoor
    Monthly feeNone

    4K applies to live view in the app; recordings are saved in 1080p Full HD.

    Use it responsibly

    Koios Pro 4K is a security camera for your own home, office or property. Let the people who live or work there know a camera is in use, and don't place it in bathrooms, bedrooms used by others, rentals where guests stay, or anywhere people expect privacy. The audio version is for in-home use only. Recording laws vary by state, and recording audio usually requires the consent of the people being recorded. It is your responsibility to follow all local, state and federal laws on video and audio recording.

    Need help?

    Zetronix tech support is free by phone, live chat and email from our US-based team. Visit the Zetronix Help Center to get in touch.

    View Koios Pro 4K on zetronix.com


  • Koios Pro - PRO-KOIOS
    +

    Koios Pro camera and USB wall charger

    This guide walks you through setting up your Koios Pro one step at a time. It takes about 10 minutes. All you need is your phone and your home Wi-Fi password.

    Koios Pro is a 1080p Wi-Fi security camera built into a USB wall charger. You watch it on your phone with the free LookCam app. There is no monthly fee.

    Part 1: Get to know your camera

    Front of Koios Pro labeled: microSD card slot, reset hole, camera lens, night-vision lights, USB-C port, USB-A port

    • microSD card slot: the memory card goes here. You only need a card if you want to save videos.
    • Reset hole: the small round hole at the top right. You only use it if something goes wrong.
    • Camera lens in the middle, with night-vision lights on both sides so you can see in the dark.
    • USB-C and USB-A ports: plug in your phone or other devices to charge them, like a normal charger.

    In the box: Koios Pro camera charger, USB card reader, user manual. A microSD card is sold separately.

    Part 2: Before you start

    Have these ready:

    • ☑ Your phone (iPhone or Android).
    • ☑ Your home Wi-Fi name and password. Write them down. Koios Pro works with 2.4 GHz and 5 GHz Wi-Fi.
    • ☑ A wall outlet indoors, with a clear view of the room.
    • ☑ A microSD memory card (optional) if you want to save videos. Use a Class 10 card, up to 256 GB.

    Part 3: Set up your camera (8 steps)

    Step 1: Put in the memory card (optional)

    Make sure the camera is not plugged in. Slide the microSD card into the slot on the front, above the lens, and push gently until it clicks.

    To take the card out later, unplug the camera, then push the card in once and it pops out.

    Step 2: Plug in the camera

    Plug Koios Pro into the wall outlet. It turns on by itself. Wait 1 minute before you go on.

    Step 3: Get the free LookCam app

    On your phone, open the App Store (iPhone) or Google Play (Android), search for LookCam and install it.

    When the app asks, tap Allow for notifications (so you get motion alerts) and, on iPhone, for finding devices on your network.

    Step 4: Connect your phone to the camera

    The camera makes its own Wi-Fi network. Let's connect your phone to it.

    1. On your phone, open Settings, then Wi-Fi.
    2. Look for a network with a long name made of letters and numbers. That is your camera.
    3. Tap it to connect. It is fine if it says "No internet" or "Connected without internet."

    Phone Wi-Fi settings: tap the camera's network, a name made of letters and numbers

    Tip: If your phone keeps jumping back to your home Wi-Fi, turn off Mobile Data (and Wi-Fi Assist on iPhone) for a few minutes while you set up.

    Step 5: Open LookCam and add the camera

    Open the LookCam app. It finds the camera on its own and asks to add it. Tap OK.

    LookCam asks to add the new camera. Tap OK.

    If your phone shows "Internet may not be available", tap Keep Wi-Fi connection.

    Message 'Internet may not be available': tap Keep Wi-Fi connection

    Step 6: See your camera

    Your camera now shows in the app with the words Device Online. (Your camera's name will be different from the picture.)

    LookCam My Device screen showing the camera with Device Online

    Tap the camera's picture to watch it live.

    • If the app asks you to make a new password, you can tap Cancel for now.
    • If the app asks for the camera's password, type 123456.

    Right now you can watch only when your phone is near the camera. Steps 7 and 8 let you watch from anywhere.

    Step 7: Connect the camera to your home Wi-Fi

    1. In LookCam, tap the gear icon ⚙ next to your camera.
    2. Tap WiFi Setting.

    Tap the gear icon next to the camera, then tap WiFi Setting

    1. Tap your home Wi-Fi in the list.
    2. Type your Wi-Fi password carefully (capital letters matter) and tap OK.

    Pick your home Wi-Fi from the list, type its password and tap OK

    1. You will see "Saved, device will reboot." Tap OK and wait 1 minute while the camera restarts.

    Message 'Saved, device will reboot': tap OK and wait about a minute

    Step 8: Put your phone back on your home Wi-Fi

    1. Open your phone's Settings, then Wi-Fi, and tap your home Wi-Fi.
    2. Turn Mobile Data back on if you turned it off.
    3. Open LookCam. When your camera says Device Online, you are done!

    You can now watch your camera from anywhere, on Wi-Fi or mobile data.

    Part 4: Everyday use

    Watch live, take a photo, record a clip

    Open LookCam and tap your camera's picture. Under the video:

    • Tap the camera button to take a photo.
    • Tap the video button to record a clip. Tap it again to stop.

    Tap the camera picture to open live view; the camera button takes a photo and the video button records

    Night vision turns on by itself when the room gets dark. The picture turns black and white, and you can see up to about 40 ft.

    Save videos to the memory card

    1. Tap the gear icon ⚙ next to your camera, then SD Card Setting.
    2. The first time, tap Format sdcard to get the card ready. (This erases everything on the card.)

    Device Setting: tap SD Card Setting, then Format sdcard

    1. To record all the time, turn on Auto Record and Loop Record. When the card is full, the oldest videos are replaced by new ones, so it never stops recording.
    2. Video Duration sets how long each video file is (for example, 5 minutes).

    SD Card Setting with Auto Record and Loop Record turned on

    Record only when something moves

    In SD Card Setting, turn Auto Record off and turn Alarm Record on. The camera then saves video only when it sees movement, which saves space on the card.

    SD Card Setting with Alarm Record turned on to record only when there is motion

    Get an alert on your phone when there is motion

    1. Tap the gear icon ⚙, then Alarm Config.

    Device Setting: tap Alarm Config

    1. Turn on Push Notifications.
    2. Tap Motion Detection Sensitivity and pick Low, Medium or High. Choose Low if you get too many alerts, High if you miss things.
    3. Tap OK to save.

    Alarm Config: turn on Push Notifications and choose the Motion Detection Sensitivity

    The camera notices movement up to about 20 ft away. Also check that notifications for LookCam are turned on in your phone's settings.

    Watch your saved videos and photos

    At the bottom of the LookCam main screen:

    • Tap Cloud/SD to watch videos saved on the memory card.
    • Tap Photo to see the photos and clips you saved from live view.

    LookCam bottom menu: Photo for snapshots, Cloud/SD for recorded videos

    On a computer: unplug the camera, take out the memory card, put it in the included USB card reader and plug that into your Windows PC or Mac. If a video won't play, use the free VLC media player.

    Charge your phone

    The USB-C and USB-A ports on the front work like a normal charger, even while the camera is recording. Let the cables hang down so they don't block the lens.

    Part 5: Where to put it

    • Pick an indoor outlet with a clear view of the room.
    • Don't point it through a window or glass. At night the glass reflects the light back and the picture turns white.
    • Keep it close enough to your Wi-Fi router for a good signal.
    • Keep it away from water, sinks and damp areas.

    Part 6: Reset the camera

    Reset if you get a new Wi-Fi router, change your Wi-Fi password, forget the camera's password, or the camera won't connect.

    1. Keep the camera plugged in.
    2. Find the reset hole (the small round hole at the top right of the front; see Part 1).
    3. Push a paperclip or pin into the hole and hold it for 15 seconds.
    4. Wait 2 minutes, then start again at Step 4.

    A reset clears the Wi-Fi and password settings.

    Part 7: If something isn't working

    I can't find the camera's network in my Wi-Fi list.
    Wait 2 minutes after plugging it in. If it still isn't there, unplug the camera for 10 seconds and plug it back in. If the camera was already connected to your home Wi-Fi, it won't show its own network; reset it (Part 6) to start over.

    LookCam doesn't find the camera.
    Check that your phone is connected to the camera's network (Step 4). Turn off Mobile Data, then close LookCam and open it again.

    The camera says Offline.
    Check that the outlet has power (some outlets are controlled by a light switch) and that your home internet is working. Move the camera closer to your router. If you changed your Wi-Fi name or password, reset the camera and do Steps 4 to 8 again.

    The camera won't join my home Wi-Fi.
    Re-type the Wi-Fi password carefully; capital letters matter. Wi-Fi networks with a sign-in page, like hotel or some guest networks, won't work.

    I'm not getting motion alerts.
    Make sure Push Notifications is on in Alarm Config, and that notifications for LookCam are allowed in your phone's settings. Check that Do Not Disturb is off.

    Videos aren't being saved.
    Check that the card is pushed all the way in (always with the camera unplugged). Format the card in SD Card Setting, and make sure Auto Record or Alarm Record is turned on. Use a Class 10 card, 256 GB or smaller.

    The video freezes or is choppy.
    Your internet may be slow. In live view, tap 1080p at the top right and choose a lower quality.

    I forgot the camera's password.
    Reset the camera (Part 6). The password goes back to 123456. When you make a new password, use only letters and numbers.

    Screens may look a little different depending on your phone and your version of the LookCam app.

    Specifications

    Video 1080p Full HD, 1920 x 1080, color by day
    Frame rate 25 fps
    Lens 140° wide angle
    Night vision 4 infrared LEDs, up to 40 ft, black and white
    Motion detection Phone alerts, up to about 20 ft
    Audio Video-only version, or video + audio version (in-home use only)
    Wi-Fi 2.4 GHz and 5 GHz
    App LookCam for iPhone and Android (free)
    Memory card microSD up to 256 GB, Class 10 (not included)
    USB charging 1 x USB-C, 1 x USB-A
    Power Standard US wall outlet; no battery
    Size About 2.3 x 1.5 x 1.8 in, plus the plug
    Operating temperature 14°F to 140°F
    Use Indoor
    Monthly fee None

    Use it responsibly

    Koios Pro is a security camera for your own home, office or property. Let the people who live or work there know a camera is in use, and don't place it in bathrooms, bedrooms used by others, rentals where guests stay, or anywhere people expect privacy. The audio version is for in-home use only. Recording laws vary by state, and recording audio usually requires the consent of the people being recorded. It is your responsibility to follow all local, state and federal laws on video and audio recording.

    Need help?

    Zetronix tech support is free by phone, live chat and email from our US-based team. Visit the Zetronix Help Center to get in touch.

    View Koios Pro on zetronix.com


  • SURGE - 3k SuperHD WiFi Smart Camera, Multi Port Surge Protector
    +

  • NODE - 4K UltraHD White WiFi Extender WIFI Security Camera
    +

  • Weather-TEMP-Black & Weather-TEMP-White
    +

See all 57 articles

Video Recording Sunglasses

See all 12 articles

DIY Cameras

See all 10 articles

Pen Cameras

Body Worn Camera

See all 16 articles

Audio Surveillance

See all 12 articles

GPS Trackers

Dash Cameras
